Applicable media: crude oil, refined oil, palm oil, etc.

The multi-dimensional jet mixer uses a purely fluid-driven design with no power or electric drive, powered by the tank-farm circulation pump. It is installed at the tank center and connected to the external circulation pump. During operation, the circulation pump pressurizes and returns the medium, which is ejected at high speed by the mixer, converting pump pressure into jet kinetic energy.

The unit rotates 360° horizontally while nozzles rotate 360° vertically, creating a full-space, full-coverage jet mixing field for complete top-to-bottom blending.

Core advantages over side-entry mixers

Compared with traditional side-entry mixers, it fundamentally eliminates three safety hazards:

No tank-wall openings: avoids long-term leakage risk;

No motor drive: completely eliminates electrical safety hazards of live operation;

No mechanical noise: purely fluid-driven with greatly reduced operating noise.

Functions and benefits

High-efficiency homogenization: dual rotary jets fully mix all layers with high uniformity and short cycles;

Tank-bottom sediment flushing: jets reach the bottom, breaking up sediment and reducing oil heel and cleaning frequency;

Energy saving: purely mechanical drive, low operating energy and 5-year maintenance-free;

Safe and reliable: no live parts or dynamic seals in the tank;

Wide application: suitable from light oils to viscous materials.
