Applicable media: refined oil, palm oil, soapstock, etc.
The jet blender has no electric drive, fully powered by the tank-farm circulation pump, installed at the tank center and connected to the external circulation system. During operation, the circulation pump pressurizes and returns the medium, and fluid pressure is converted into high-speed jets at the nozzles. The unit rotates 360° horizontally, and precisely designed nozzle angle, jet velocity, vortex direction and laminar-flow height create a three-dimensional jet swirl field, driving full convection mixing of the upper, middle and lower materials for uniform blending.
Replacement advantages
Compared with traditional side-entry mixers, it structurally eliminates three typical safety and operating hazards: no tank-wall leakage risk (no side-wall mounting holes); no live-operation hazard (no electrical parts in the tank); no mechanical drive noise (purely fluid-driven, smooth and quiet).
Core value
High blending quality (three-dimensional swirl with no dead zones); three-dimensional swirl mixing (360° rotation + multi-angle nozzle jets); low energy consumption (uses existing circulation pumps); long maintenance-free cycle (simple mechanical structure, 5-year maintenance-free); easy installation (center-mounted, no damage to side walls).
